Product Specification
- Operating Freq. : 47-400Hz
- Max. Operating Voltage : 300VAC
- Ambient Temp : -40 to 70C
- Hipot Rating (L-G) : 1800VDC
- Typ Weight. LBS (KG) : 0.42 (0.2)
- Terminals : M5 Stud
- Leakage Current : <3.5mA
PART NUMBER / ORDERING
| MODEL | AMPERAGE |
|---|---|
| PFM55S-5-22 | 5 |
| PFM55S-10-22 | 10 |
| PFM55S-15-22 | 15 |
| PFM55S-20-22 | 20 |
TYPICAL INSERTION LOSS (50/50ohm)
| FREQ MHZ) | 0.01 | 0.1 | 0.5 | 1.0 | 10 |
|---|---|---|---|---|---|
| CM, dB | 18 | 24 | 52 | 55 | 48 |
| DM, dB | 24 | 42 | 61 | 60 | 42 |
